499 Spout Assembly

499 Spout Assembly

Parts

Sch. ID Product Image Kooima Ag # Title Replaces OEM # Price Quantity
0 K1416840 Wear Plate 1416840 $225.00
1 K1431730 Spring Angle 1431730 $7.10
2 K1417890 Plate 1417890 $25.00
3 K1445030 Replacement HD Spout Plate 1445031 $41.75
3a K1435090 Wear Plate 1435090 $32.50
4 KBK Wear Plate Bolt Kit $4.75
4a K1409621 Inner Deflector 1409622 $135.00
5 K0766312BK Spout Deflector Bolt Kit $8.75
5a K1419110 Strap 1419110 $22.50
6 K0766312 Outer Spout Deflector 766314 $86.50
